Brass Bodied Check Valve with an Internal Buna-N Duckbill, 10-32 UNF Female Ports, Cracking Pressure 1 psi

Brass Bodied Check Valve with an Internal Buna-N Duckbill, 10-32 UNF Female Ports, Cracking Pressure 1 psi

E-C-180027

Brass Bodied Check Valve with an Internal Buna-N Duckbill, 10-32 UNF Female Ports, Cracking Pressure 1 psi

Brass Bodied Check Valve with an Internal Buna-N Duckbill, 10-32 UNF Female Ports, Cracking Pressure 1 psi
BUY ONLINE
REQUEST A QUOTE
X

Bulk price quote request

Product Details

E-C-180027

Brass Bodied Check Valve with an Internal Buna-N Duckbill, 10-32 UNF Female Ports, Cracking Pressure 1 psi

Personal Details

Please enter a CompanyPlease enter a valid Company, the maximum length is 50 characters

Please select a valid Title, the maximum length is 12 characters.

Please enter a First NamePlease enter a valid First Name, the maximum length is 50 characters.

Please enter a Last NamePlease enter a valid Last Name, the maximum length is 50 characters.

Contact Details

Please select a valid Contact Number, the maximum length is 30 charactersPlease enter a valid Contact Number consisting only of the following characters & spaces ( ) + 0 1 2 3 4 5 6 7 8 9

Please enter a valid Email AddressPlease enter a valid Email AddressThe Email Address entered is already registered, please sign in with the Email Address or enter a different one

Please enter a QuantityPlease enter a valid number between 10 and 999999

Please confirm you are not a robot.
We have been unable to verify your identity, please confirm you are not a robot.

Description Brass Bodied Check Valve with an Internal Buna-N Duckbill, 10-32 UNF Female Ports, Cracking Pressure 1 psi

Extended Description An in-line Brass bodied check valve with an internal Brass poppet and Buna-N seals, 10-32 UNF Female ports and a cracking pressure of 1 psi

Ambient Temperature 0°C – 110°C (32°F – 230°F)

Mounting Style In-line

Connection 1 10-32 UNF Female Thread

Connection 2 10-32 UNF Female Thread

Media Temperature 0°C – 110°C (32°F – 230°F)

Non-Wetted Materials Brass

Wetted Materials Brass, Buna-N

Cleanroom Manufactured No

Max. Inlet Pressure 6.89 bar (100 psi)

Flow Rate Approximately 28 l/min at 3.5 bar

Min Inlet Pressure 0.17 bar (2.5 psi) To Fully Open the Check Valve

Cracking Pressure 1 bar (0.069 psi)

Item Weight 0.0090Kg (9g)

ROHS Compliant Yes

CE Mark No

REACH Compliant Yes

Other Technical Data These valves are compatible with Air and Hydraulic Oil; they are not intended for use as a pressure relief valve. A check valve is generally used in a pneumatic circuit which requires free flow in one direction (Normally indicated with an arrow on the check valve) and no flow in the opposite direction, they can also be useful as a bypass valve allowing flow around other circuitry components such as needle valves which would restrict the flow in both directions. For further information please contact us on +44 (0)2392 266031

Disclaimer: All information has been carefully collated and presented, however, The West Group Ltd cannot accept responsibility for incorrect or misprinted information

Dimensional Drawing (pdf)

3D model (IGS)
